11
3 Technical data
3.1 Components
Note: The adsorption dryer displayed on the pictures of this
manual is A-DRY 6 from A-DRY series adsorption dryer.
Part
1 Control valves
2 Consoles
3 Tower 1
4 Tower 2
5 Controller
6 Pressure indicator
7 Inlet
8 Outlet
3
4
2
8
7
2
1
6
5
