14
3.3 Pressure Equipment Directive PED 2014/68/EU
(Fluid group 2)
Technical datasheet is available. For additional technical specification contact the
manufacturer.
3.4 Electrical characteristics
DRY 6/12/24/36/60/75/105/150/200 Category I, Module A
Supply voltage 230 V ± 10 % 110 V ± 10 %
Supply frequency 50 Hz
Power consumption <40 W for DRY 6 to DRY 105
<70 W for DRY 150 to DRY 200
Stand-by contact 24 VDC
Protection class -
housing
IP 65
Digital output Type of contact Voltage free NO or NC
Maximum switching voltage 250 Vac or 30 Vdc
Maximum switching current 3 A
Dielectric strength of contacts to PE 4 kVA
Digital input Voltage across free contacts 3,3 V
Current through contact 40 µA
Negative contact is grounded
Analog input Type 4…20 mA
Supply voltage 24 V
Input resistance 100 Ω
Short circuit protected
Maximum input voltage 3 V
Negative contact is grounded
