9 Installation
9.1 Initial inspection
Adsorption dryer could be damaged during transportation. Putting a damaged adsorption
dryer into operation can result in injury or death! Check the adsorption dryer for any visible
damage after removing the packaging. If the adsorption dryer is damaged contact the
transportation contractor and supplier. Damaged adsorption dryer should not be put into
operation!
9.2 General Installation Requirements
DRY series adsorption dryer is designed to be installed in a place that meets the following
requirements:
• Indoor installation (clean and dry)
• Non aggressive atmosphere
• Ambient temperature 1,5°C to 60°C
• Non explosive environment (Standard version DOES NOT COMPLY WITH ATEX)
• Vibration free installation (refers to floor and piping)
Compressed air which is supplied to DRY needs to meet the following requirements:
• Compressed air quality 2 for solid particles (if dryer is equipped with superfine
coalescing filter 0,01µm)
• Compressed air quality 1 for solid particles (if dryer is not equipped with superfine
coalescing filter 0,01µm)
• Compressed air quality 2 for oil (if dryer is equipped with superfine coalescing filter
0,01µm)
• Compressed air quality 1 for oil (if dryer is not equipped with superfine coalescing
filter 0,01µm)
• Free from aggressive substances
• Free from substances which could damage adsorbent (if you are not sure about
certain substance please contact manufacturer)
• Preferably compressed air should be saturated with moisture (100% relative
humidity). Lower relative humidity can reduce efficiency.
