41
12 Additional equipment
It is necessary that a condensate separator and a pre-filter be installed at the inlet side and
an after-filter at the outlet side!
Condensate separator removes liquid water and other liquid content from compressed air
flow. Removing liquid water and other liquid content with the condensate separator ensures
the efficient drying and long life of the molecular sieve. Condensate drain has to be installed
on the condensate separator!
Pre-filter removes the particulate matter from the compressed air flow and extends the life
of the molecular sieve. Pre-filter should be at least ISO 8573-1 Class 6 particle filter (3 µm
particles). Install the condensate drain on the pre-filter housing!
After-filter cleans the outlet air of any particulate matter originating from molecular sieve.
After-filter should be at least ISO 8573-1 Class 3 particle filter (1 µm particles). It is
recommended that all filters and the after-filter in particular be equipped with the pressure
drop indicator to efficiently detect filter element clogging.
Below is the information on the recommended condensate separators, pre-filters, after-
filters and condensate drains that can be ordered as additional equipment for the
adsorption dryers.
EQUIPMENT MODEL DESCRIPTION
Condensate separator CKL-B series Condensate separators
Pre-filter AF series P filter Compressed air Class 6 filters
After-filter AF series R filter Compressed air Class 3 filters
Condensate drain
AOK16B Automatic mechanical cond. drain
AOK20B Automatic mechanical cond. drain up to 167 l/h
TD M/S series Timer controlled cond. drains up to 95 l/h
EMD series Electronic condensate drains up to 12 l/h
CDI 16B series Electronic condensate drains up to 45 l/h
ECD-B series Electronic condensate drains up to 150 l/h
Pressure drop indicator
PDi16 Compact differential pressure indicator
MDA60 Differential pressure indicator
MDM40 Magnetic differential manometer
MDM60 Magnetic differential manometer
MDM60E
Magnetic differential manometer, electronic, LED alarm,
battery powered
MDM60C
Magnetic differential manometer, voltage-free contact
for remote alarm
EPG60 series
Electronic pressure gauge, LED display, alarm, battery
powered, filter cartridge condition diagnostic algorithm
Contact your supplier for additional equipment details.
