Wiring Connections (cont’d)
SECONDARY 7 PIN HARNESS
YELLOW/GREEN: (-) OEM Alarm Disarm Output- This wire mimics the BLUE
unlock wire and is used for disarming factory installed alarm systems. It is a
250mA negative output.
BROWN: (-) Horn Honk Output- Connect this to the vehicle’s horn switch cir-
cuit. It is a 1A negative output that is directly compatible with most horn circuits.
Add a relay if the vehicle requires higher amperage or positive polarity.
WHITE/RED: (+/-) Flashing Light Polarity Selection- This is the input to the
ashing light relay. Connect the bullet connector on the end of this wire to the
mating connector on either the RED (+) or BLACK (-) wire to select the desired-
polarity. The polarity is determined by the vehicle’s light circuit.
PINK: (-) 3nd Channel Output- This wire, by default, has a 1 second 250mA
negative output whenever the “
...
“ transmitter is held for 3 seconds. The timing
is congurable with feature #12. It is typically used to activate accessories like
a remote start unit.
WHITE: (+/-) Light Flash Output- By default, this wire is connected to the ve-
hicle’s parking light circuit. It’s polarity is determined by the WHITE/RED wire.
If ashing lights are not desired, this output can be congured to operate as 4th
channel using feature #7.
WHITE/BLACK wires: (+/-) Domelight Supervision Output- By default, these
wires will turn on the vehicle’s interior lights for 30 seconds after unlocking by
the transmitter. Connect the FUSED wire to either +12v or ground, depending
on the vehicle’s light circuit requirements. Connect the NON-FUSED wire to the
domelight circuit in the car.
The REC-12 has a 4 pin plug-in door lock/unlock port. It provides 3
250mA outputs for LOCK, UNLOCK #1 (driver’s OR all doors), and UNLOCK
#2 (all doors for driver’s priority). It also has a constant +12V output for power-
ing optional relay coils. It offers installation exibility because every doorlock
interface available from Omega R & D, Inc. will plug directly into this port. There
are 4 primary types of analog doorlocking systems used in vehicles today.
Additionally, there are digital databus driven systems that require an interface
module. Refer to vehicle specic information to determine which doorlocking
system is used.
Mutliplex Doorlocks: This is the newest type of analog doorlock
control system developed for vehicles. It typically uses only 1 wire for lock and
unlock control. It can be positive or negative and the vehicle’s body computer
looks for multiple signals on this wire. Each signal differs in voltage. This is
controlled by resistors in the doorlock switch which must be mimiced by the
doorlock interface. Refer to vehicle specic information for more details.
DOOR LOCK CONNECTIONS
To Next Page
