Omlet Eglu Cube Instruction Manual

Page6
The Roof Panel is fi tted in a similar
way to the Large Side
Panels.
Firstly loosely bolt the panel to the
Front Face with four Small Bolts
and four Large Flat Washers.
Clip the Roof Panel to the Large
Side P
anels in the positions shown,
(mirror these positions for the
other side.) Finally tighten up the
four Small Bolts.
Firstly clip the Skirt Panel to the
bottom of the Lower Front panel.
Clip it on such th
at it underlaps
the panel by one rectangle and
the largest part of the Skirt Panel
sticks out on the side that the door
opens.
You can now clip this whole
assembly to the end of the run.
Start by lining up and clipping
the bottom of each side and
work your way up to avoid an
y
misalignment.
First bolt the panel loosely to the
Front Face using two Small Bolts
and two Large Flat Washers. (The
top bolt goes through the second
mesh hole down as shown.)
Clip the Large Side Panel to the
Small Side Panel.
This will be
easier if you raise this side of the
eglu using the wheel
. Lower the
eglu back down and then tighten
the bolts.
The image
shows the Right Large
Side Panel only. Now repeat the
process for the other side.
Step 10 - Attach the Large Side Panels
Step 11 - Attach the Roof Panel
If you have an extension
Now is the time to attach it. Go to
the next page for fi tting instructions.
Step 12 - Attach the End of the Run and Skirt Panel

Omlet Eglu Cube Specifications

General

Ventilation	Adjustable ventilation system
Capacity	Up to 10 chickens
Features	Easy to clean, secure fox-resistant run, integrated nesting box
Color	Green or Purple
Portability	Fitted with wheels for easy movement
Included Accessories	Nesting box, roosting bars
