Section 5. System Operation
5-3
4)
INSTANT LED
This LED/display indicates that the system has been armed in the INSTANT or STAY/INSTANT
mode, meaning that the system is currently armed, all delay zones are instant (no delay time). See
programming Question 14, Location 1.
ON Delay zones are currently instant
OFF Delay zones are normal
5)
AC/LOW BATTERY LED
This LED/display indicates the current power status of the panel as follows:
ON AC is present
OFF No AC, running on battery backup
Slow Blink Low-battery condition detected
6)
READY LED
This LED/display indicates that the system is ready for arming. The READY LED is common to all
BURGLARY ZONES with the following indications:
ON System ready to be armed
OFF System not ready to be armed
Slow Blink Indicates Installer programming mode
Fast Blink Alarm Memory mode
7)
[STAY] BUTTON
The [STAY] button arms the system, excluding zones programmed as Stay/AutoStay zones. This
provides exterior protection of the premises while allowing full access throughout the interior.
8)
[BYPASS] BUTTON
The [BYPASS] button is used to temporarily exclude protection to a specific zone(s).
9)
[INSTANT] BUTTON
If pressed, the [INSTANT] button allows arming the system in the INSTANT mode; with the
[STAY] button, it enables arming the system in the STAY/INSTANT mode.
NOTE:
INSTANT mode is enabled in Question 14, Location 1.
10)
[CODE] BUTTON
The [CODE] button is used to allow entry into the Installer programming mode and permits the
entry of user codes.
11)
KEYPAD AUXILIARY KEYS
Pressing the auxiliary keys (XK-108L: two keys labeled P, A, or F at the same time; OMNI-
LCD/OMNI-KP: 1/3, 7/9,
✱
/#) initiates a CS transmission, if programmed, of programmed functions
(e.g., PANIC, AUXILIARY, or FIRE), and causes annunciation of the keypad sounder and turns on
the bell output. The programmed functions are defined in Programming Submode 1, Questions 26
and 27.
See “Keypad Emergency Conditions” in this section for alternate auxiliary keys.
