OMNI-624/OMNI-624EU Installation and Setup Guide
6-18
Q 12, L2 – Enter the digit for the desired options from the table below.
AC Freq.
L2
Entry
XL4705 Relay
Enable
60Hz 50Hz
RF Receiver
Enable
0
✔
1
✔
2
✔✔
3
✔✔
4
✔
5
✔
6
✔✔
7
✔✔
8
✔✔
9
✔✔
A
✔✔ ✔
B
✔✔ ✔
C
✔✔
D
✔✔
E
✔✔✔
F
✔✔✔
4705 Relay Enable:
Enables the Relay
Module. If used, the system’s built-in triggers 3
and 4 will no longer be available as triggers.
Instead, they will serve as clock and data lines,
respectively, for the relay module.
AC Frequency:
Select the AC line frequency,
50Hz or 60Hz.
ZR-401/ZR-402EU/OMNI-RF RF Enable:
Enables the RF expander module, if used.
Q 12, L3 – Enter the digit for the desired options from the table below.
User Codes
L3
Entry
Euro Pulse
Dialing (66:33)
TouchTone
Dialing
U.S. Pulse
Dialing (60:40)
4-Digit 6-Digit
Bell/Siren
Supervision
0
✔✔
1
✔✔
2
✔✔
4
✔✔
5
✔✔
6
✔✔
8
✔✔ ✔
9
✔✔✔
A
✔✔✔
C
✔✔✔
D
✔✔✔
E
✔✔✔
Dialing Method
:
Select the type of dialing desired.
User Codes 4/6 digits:
The system supports either 4-digit or 6-digit user codes. If this option is
selected, the system is set to use 6-digit codes. Existing 4-digit user codes will be automatically changed
to include “00” before the existing code (e.g., 1234 becomes 001234). If the system is set to 6-digit codes
and is changed to 4-digit codes, the first two digits of existing 6-digit user codes will be automatically
deleted (e.g., 123456 becomes 3456).
