Section 6. System Programming
6-37
QUESTION 30 AUTO-ARM TIME PARTITION 2
L1 L2 L3 L4
Hours (00-23) Minutes (00-59)
QUESTION 31 NOT USED
QUESTIONS 32–43 TRIGGER/RELAY TYPES
These questions set relay and trigger types. Momentary trigger times in seconds or minutes for each
partition are set in Questions 65 and 66.
Each trigger definition requires 2 locations to define its operation. L1 defines the partition in addition
to the type that the trigger is to respond to. L2 completes the type definition entry. Some triggers types
are not partition-independent functions, such as loss of AC. Triggers that are momentary can follow
either a second timer or a minute timer as described for that trigger type. Each partition has both a
minute and second programmable time. Note that all momentary triggers for a partition will follow the
momentary time (seconds or minutes) programmed for that partition. Each timer may be programmed
for 1-15.
NOTE:
Triggers 3 and 4 (Question 43) may not be programmed if the 4705 Relay Module is enabled
(Submode 1, Question 17, Location 2).
Enter a relay type from the following table for each relay used.
P1 P2 Relay Type Description
00 00 Disabled
01 41 Burg Bell no Bell Test Turns on with the burg bell and turns off when the bell times out or is shut
off.
02 42 Fire Bell no Bell Test Follows the same temporal pattern as the fire bell. Turns off when the fire
bell times out or is turned off.
03 43 Partition Armed Is on when the selected partition is armed; otherwise is off.
04 44 Partition Ready Is on when the selected partition is disarmed; otherwise is off.
05 45 In Entry Delay Is on if the selected partition is in entry delay; otherwise is off.
06 46 In Exit Delay Is on if the selected partition is in exit delay; otherwise is off.
07 47 Armed Instant Is on if the selected partition is armed in the instant mode; otherwise is off.
08 48 Armed Stay Is on if the selected partition is armed in the stay mode; otherwise is off.
09 49 Sounder on/pulsing Follows either a pulsing sounder or steady sounder for the selected
partition.
0A 4A Chime Is activated for 1 second if a chime zone is activated for the programmed
partition.
0B n/a Line Seize (System) System trigger is on if the home phones are disconnected.
0C n/a Phone Fail (System) System trigger is on if the phone line monitor has detected the phone line
has been cut.
0D n/a AC Loss (System) System trigger is on when no AC loss is detected.
0E n/a Low Battery (System) System trigger is on when the battery voltage falls below 10.2 volts.
0F 4F 24 Hr Zone in Trouble On if any 24-hour trouble in the selected partition is active.
10 50 24 Hr Zone Alarmed On if any 24-hour alarm zone in the selected partition is active.
11 51 Instant Zone Faulted On if any instant zone in the selected partition is faulted.
12 52 Delay Zone Faulted On if any delay zone is faulted in the selected partition.
