OMNI-624/OMNI-624EU Installation and Setup Guide
6-38
P1 P2 Relay Type Description
13 53 Interior Zone Faulted On if any interior zone is faulted in the selected partition.
14 54 Zone Tamper On if any Tamper has occurred on a zone. Includes RF and hardwired (if
double balanced).
15 55 RF Low Battery On if any low battery has been detected on an RF zone for that partition.
16 56 RF Supervision On if any RF zone has not been received for the programmed supervision
interval.
17 n/a Comm. Fail (System) On when comm fails occurs, off after code is entered, by partition.
18 58 Key Tamper, mom. Sec By partition, if 21 keys are entered without a valid code, keypad tamper
activates momentarily for the number of seconds programmed for that
partition.
19 59 Duress Code, mom. Sec By partition, momentary output based on Seconds. Activated when user
codes 31–32 are enabled for duress (ambush).
1A 5A Bell Strobe - Internal, No
dings
On with either fire or burg, off with code.
1B 5B Bell Strobe - External, with
dings
With arm/disarm dings. Latches on with either a fire or burg bell, off with
code.
1C 5C Trigger Zone, mom Minutes Follows the zone type - trigger. Momentary based on minutes.
1D 5D Trigger Zone, mom. Seconds Follows the zone type - trigger. Momentary based on seconds.
1E 5E Door Strike, mom. Seconds Activates for seconds upon valid user code or user code 20–30 as
enabled in installer programming.
1F 5F Shock Reset (*) Seconds Momentary trigger for seconds when the “*” key is pressed.
20 60 CS Test Momentary Secs. Momentary second trigger, when CS test transmits to CS.
21 61 Alarm/Restore by partition By partition, goes on with alarm and off when all zones for the partition
have met their restore requirements.
22 62 2-way voice, on after seize
rel.
Works in conjunction with a two way voice module. The trigger activates
after the dialer is done for the minutes programmed for partition 1. The
keypad sounders are silenced until either bell cut-off or a valid user code
is entered.
23 63 Momentary by Seconds
(fob, soft)
May be activated by any soft key if programmed.
24 64 Momentary by Minutes
(fob, soft)
May be activated by any soft key if programmed.
25 65 Toggle (Keyfob, softkeys) May be activated by keyfobs or soft keys.
26 66 Follows Zn Loop, Trig=Zn 1–
20
For the first 20 zones only. The trigger offset is equal to the zone number.
Example trigger 2 follows the normal/off normal state of zone 2.
27 67 Follows Zn Loop, Trig=Zn 21–
24
Same as type 26, but for zones/triggers 21–24
28 68 Zone alarm - zones 1–20 Zones 1–20 = triggers 1–20. On with zone alarm, off when zone is
cleared.
29 69 Zone alarm - zones 21–24 Zones 21–24 = triggers 1–4. On with zone alarm, off when zone is
cleared.
2A 6A Zone alarm restore - zones 1–
20
Zones 1–20 = triggers 1–20. On with zone alarm, off when restore for
zone occurs. This is based on Restore Follows Loop option.
2B 6B Zone alarm restore - zones
21–24
Zones 21–24 = triggers 1–4. On with zone alarm, off when restore for
zone occurs. This is based on Restore Follows Loop option.
2C 6C Sys Bell, Internal (no Dings) Follows bell output but does not respond to bell test.
2D 6D Sys Bell, External (with Dings) Follows bell output, but responds to bell test.
