Section 6. System Programming
6-45
QUESTIONS 01–24 ZONE TYPES AND ATTRIBUTES
L1 L2 L3 L4
Zone Part./ silent/ stay/chime
Type config swing dial delay
These questions are used to program zone information. Use the separate Programming Form to enter
the actual values for each zone. For each of the following questions, enter the digits as follows:
L1: – Zone Types
Zone Type
L1
Entry
Controlled
Description
0
Disabled Will not affect the system in any way.
1
Instant An instant zone shows “not ready” when disarmed and goes immediately into alarm when
faulted while armed.
2
Delay A controlled zone that is bypassed during entry and exit. Starts entry time 1 if violated while
the system is armed. If the system is not disarmed before the end of entry time, an alarm is
generated.
3
Delay 2 Same as Type 2 except uses the entry 2 time.
4
Interior Upon arming, this zone begins system exit delay and will cause an alarm if faulted when exit
delay ends. With system armed, faulting an entry delay zone causes “interior” zones to begin
the respective entry delay (depending on the entry zone faulted), during which time the zone
can be faulted. Interior zones cause immediate alarms if faulted without an entry zone being
activated first (while the system is armed).
5
Day Zone When faulted, causes trouble when disarmed and an alarm while armed.
24-Hour
8
Keyswitch Used to arm/disarm the control by momentary, non-latching switch.
9
Trigger/Relay
Zone
Zone’s status (fault/normal) determines activation of associated trigger/relay. See trigger/relay
programming in Submode 1, Questions 23–29 to enable appropriate trigger or relay.
A
Trouble Zone Produces a trouble condition on zone with an option for a pulsing keypad sounder.
B
Alarm Zone Activates burg bell on any faulted condition. If zone is off (normal after alarm memory is
cleared), the alarm is converted to a trouble display.
C
Alarm/Trouble 24-hour zone that causes an alarm with the burg bell on a short and a trouble condition on an
open. Must be EOL to derive trouble condition. Dialer sends zone alarm code for short and
trouble code for open.
E
Fire, No
Verification
Fire zone that works like a 24-hour alarm zone but uses the fire bell. This zone type is usually
used for a switched input such as a pull station.
F
Fire, With
Verification
Intended for a 4-wire smoke detector connected to the smoke power terminals. A short
produces a temporal fire bell and an open produces a zone trouble. Must be E.O.L. to derive
the trouble condition.
Verification process: Verification will not occur if any fire zone in the system is already in
alarm. Upon detection of a short, power is removed from the smoke detector power terminals
for 8 seconds. After restoring power, the system waits another 4 seconds, then tests the zone
again. If a short still exists, an alarm occurs.
Fire Trouble: Fire trouble occurs in 2 different ways. The first way is for the loop to open. The
second way is if the loop is still shorted after a fire alarm has been silenced and the user
clears alarm memory. The alarm is changed to a trouble. No trouble is reported to the CS at
this time (serves as a reminder to let the end user know the zone is not active). On clearing
alarm memory, if a fire verification zone is still shorted the verification process is repeated
about every 4 minutes to try to reset the smoke detector. A tamper on a fire zone results in a
trouble, not an alarm.
