OMNI-624/OMNI-624EU Installation and Setup Guide
6-46
L2: – Partition, zone configuration, supervision options
Partition Hardwire Loop Type Wireless Supervision
L2
Entry
1 2 EOL N/C N/O Supervise Tamper
0
✔✔ ✔✔
1
✔✔ ✔ ✔
4
✔✔ ✔
5
✔✔ ✔
8
✔✔✔
9
✔✔✔
Partition:
Select the partition in which
the zone is located.
Hardwire Loop Type –
If this is a
hardwire zone, select the type of loop.
This selection is
not
applicable for
double-balanced, fast, or zone doubling
zones. For EOL, use a 2.2k loop resistor.
Wireless Supervision –
If this is a
wireless zone, select whether it will be
supervised and/or have tamper
protection active.
L3 Entry:
L3
Entry
Silent
Zone Swinger*
0
1
✔
2
✔
3
✔✔
* Erratic or unstable sensor
Silent –
If selected, alarms will be sent to the central station but no
sounding (bell, keypad sounder) will occur.
Swinger –
If selected, this zone will stop reporting alarms during a
single armed period if the number of alarms within that armed period
exceeds the number set in Submode 1, Question 10, Location 4.
L4 Entry:
L4
Entry Stay
Auto-
Stay Chime
Dial
Delay
0
1
✔
2
✔
3
✔✔
4
✔
5
✔✔
6
✔✔
7
✔✔✔
8
✔
9
✔✔
A
✔✔
B
✔✔ ✔
C
✔✔
D
✔✔✔
E
✔✔✔
F
✔✔✔✔
Stay –
If selected, zone will be bypassed if the system is
armed in STAY mode.
Auto-Stay –
If selected, zone will be automatically
bypassed if a delay zone (e.g. entry/exit door) is not faulted
during exit delay.
Chime –
If selected, a fault on this zone while the system
is disarmed allows the keypad to emit a 1-second beep.
When this feature is selected, the beep may be turned on or
off by the user entering the #6 command.
Dial Delay –
If selected, transmission of alarms on this
zone will be delayed by the time selected in Question 19,
Location 4.
To Next Page
