Appendix A:User Manual of SMPM100
1. Product Information
1.1. Overview
The monitor is shown in the picture below.
1.2. Datasheet
Interface
PLCC
Proprietary
Ethernet
RJ45
RS485
RJ45
Capacity
Numbers of devices connected
Monitor up to 40 units PV models*
Power Requirements
AC Supply
220V/230V/240V;50Hz/60Hz
Power Consumption
1W
Object
Description
A
network cable
B
monitor
C
electrical wire
B
C
A
