12
Technical Specifications
EP-220NET
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 6 W
Frequency range: 20-20000 Hz, ± 0.5 dB
Distortion factor: 0.1 %
S/N ratio: 100 dB
Input impedance: 20 kΩ (balanced), 10 kΩ (unbalanced)
Input sensitivity: 1 V
Input connectors:
Line 1-4: RCA L/R
Mic: combination XLR/6.3 mm jack, unbal.
Aux: 3.5 stereo jack
Output connectors: RCA L/R, XLR L/R, 6.3 mm jack L/R
Digital connectors: Optical (Toslink), coaxial (SPDIF)
WLAN standard: IEEE 802.11g/b/n, 2.4 GHz
Security protocol: WEP/WPA/WPA2
Ethernet/LAN: 10/100 mbit/s (RJ-45)
Bluetooth version: V4.2 BR/EDR
Bluetooth range: approx. 10 m
Bluetooth transmission power: 0 dBm
Supported audio formats: .mp3, .aac, .aac+, .flac
Frequency range: FM 87.5-108 MHz
Dimensions (LxWxH): 483 x 190 x 44 mm
Rack installation with 1 U, mounting brackets removable
Weight: 1.9 kg
Battery remote control: 2 x micro (AAA)
Specifications are subject to change without notice due to product improvements.
Connector Configuration
