Omron 3G3RX2-A2 Series Quick Start Guide

1
2
3
G
3
R
X
2
S
e
r
i
e
s
Hig
h
-
f
unc
t
ion
G
e
neral
-
p
ur
p
ose
I
n
verter
Us
e
r
’s
Manu
a
l
(I620)
Code Function name Monitoring and setting items
Units
AC216 Accel1 to Accel2 Frequency transition point, 2nd-motor 0.00～590.00（Hz）
0.01Hz
AC217 Decel1 to Decel2 Frequency transition point, 2nd-motor 0.00～590.00（Hz）
0.01Hz
AC220 Acceleration time setting 1, 2nd-motor 0.00～3600.00（s）
0.01s
AC222 Deceleration time setting 1, 2nd-motor 0.00～3600.00（s）
0.01s
AC224 Acceleration time setting 1, 2nd-motor 0.00～3600.00（s）
0.01s
AC226 Deceleration time setting 1, 2nd-motor 0.00～3600.00（s）
0.01s
AC-30 Acceleration time setting for Multispeed-1 0.00～3600.00（s）
0.01s
AC-32 Deceleration time setting for Multispeed-1 0.00～3600.00（s）
0.01s
AC-34 Acceleration time setting for Multispeed-2 0.00～3600.00（s）
0.01s
AC-36 Deceleration time setting for Multispeed-2 0.00～3600.00（s）
0.01s
AC-38 Acceleration time setting for Multispeed-3 0.00～3600.00（s）
0.01s
AC-40 Deceleration time setting for Multispeed-3 0.00～3600.00（s）
0.01s
AC-42 Acceleration time setting for Multispeed-4 0.00～3600.00（s）
0.01s
AC-44 Deceleration time setting for Multispeed-4 0.00～3600.00（s）
0.01s
AC-46 Acceleration time setting for Multispeed-5 0.00～3600.00（s）
0.01s
AC-48 Deceleration time setting for Multispeed-5 0.00～3600.00（s）
0.01s
AC-50 Acceleration time setting for Multispeed-6 0.00～3600.00（s）
0.01s
AC-52 Deceleration time setting for Multispeed-6 0.00～3600.00（s）
0.01s
AC-54 Acceleration time setting for Multispeed-7 0.00～3600.00（s）
0.01s
AC-56 Deceleration time setting for Multispeed-7 0.00～3600.00（s）
0.01s
AC-58 Acceleration time setting for Multispeed-8 0.00～3600.00（s）
0.01s
AC-60 Deceleration time setting for Multispeed-8 0.00～3600.00（s）
0.01s
AC-62 Acceleration time setting for Multispeed-9 0.00～3600.00（s）
0.01s
AC-64 Deceleration time setting for Multispeed-9 0.00～3600.00（s）
0.01s
AC-66 Acceleration time setting for Multispeed-10 0.00～3600.00（s）
0.01s
AC-68 Deceleration time setting for Multispeed-10 0.00～3600.00（s）
0.01s
AC-70 Acceleration time setting for Multispeed-11 0.00～3600.00（s）
0.01s
AC-72 Deceleration time setting for Multispeed-11 0.00～3600.00（s）
0.01s
AC-74 Acceleration time setting for Multispeed-12 0.00～3600.00（s）
0.01s
AC-76 Deceleration time setting for Multispeed-12 0.00～3600.00（s）
0.01s
AC-78 Acceleration time setting for Multispeed-13 0.00～3600.00（s）
0.01s
AC-80 Deceleration time setting for Multispeed-13 0.00～3600.00（s）
0.01s
AC-82 Acceleration time setting for Multispeed-14 0.00～3600.00（s）
0.01s
AC-84 Deceleration time setting for Multispeed-14 0.00～3600.00（s）
0.01s
AC-86 Acceleration time setting for Multispeed-15 0.00～3600.00（s）
0.01s
AC-88 Deceleration time setting for Multispeed-15 0.00～3600.00（s）
0.01s
Ad-01 Torque reference input source selection
01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal [Ai3]) /04
(Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6]) /07 (Setting
by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse train
input(internal)) /13 (Pulse train input(Option)) /14 (Setting by EzSQ) /15 (PID function)
―
Ad-02 Torque reference value setting −500.0～500.0（%）
0.1%
Ad-03 Polarity selection for torque reference 00 (As indication by the sign) /01 (Depending on the operation direction)
―
Ad-04 Switching time of Speed contorl to Torque control 0～1000（ms） ―
Ad-11 Torque bias input source selection
00 (Disable) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) 09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse
train input(internal)) /13 (Pulse train input(Option)) /15 (PID function)
―
Ad-12 Torque bias value setting −500.0～500.0（%）
0.1%
Ad-13 Polarity selection for torque bias 00 (As indication by the sign) /01 (Depending on the operation direction)
―
Ad-14 Terminal [TBS] active 00（Disable）/01（Enable） ―
Ad-40 Input selection for speed limit at torque control
01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal [Ai3]) /04
(Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6]) /07 (Setting
by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse train
input(internal)) /13 (Pulse train input(Option))"
―
Ad-41 Speed limit at torque control (at Forward rotation) 0.00～590.00（Hz）
0.01Hz
Ad-42 Speed limit at torque control (at Reverse rotation) 0.00～590.00（Hz）
0.01Hz
AE-01 Electronic gear setting point selection 00 (Feedback side) /01 (Reference side)
―
AE-02 Electronic gear ratio numerator 1～10000
―
AE-03 Electronic gear ratio denominator 1～10000
―
AE-04 Positioning complete range setting 0～10000（Pulse）
1pls
AE-05 Positioning complete delay time setting 0.00～10.00（s）
0.01s
AE-06 Position feed-forward gain setting 0～655.35
0.01
AE-07 Position loop gain setting 0.00～100.00
0.01
AE-08 Position bias setting −2048～2048（Pulse）
―
AE-10 Stop position selection of Home search function 00 (Setting by parameter) /01 (Option-1) /02 (Option-2) /03 (Option-3)
―
AE-11 Stop position of Home search function 0～4095
1
AE-12 Speed reference of Home search function 0.00～120.00（Hz）
0.01Hz
AE-13 Direction of Home search function 00（forward）/01（reverse）
―
