Code Function name Monitoring and setting items
Units
AH-75 PID soft start function enable 00（Disable）/01（Enable） 0.01%
AH-76 PID soft start target level 0.00～100.00（%） 0.01%
AH-78 Acceleration time setting for PID soft start function 0.00～3600.00（s） 0.01%
AH-80 PID soft start time 0.00～100.00（s） 0.01%
AH-81 PID soft start error detection enable 00 (Disable) /01 (Enable(Error output)) /02 (Enable(Warning output)) 0.01%
AH-82 PID soft start error detection level 0.00～100.00（s） 0.01%
AH-85 PID sleep trigger selection 00 (Disable) /01 (Low output) /02 (Terminal [SLEP] input) 0.01%
AH-86 PID sleep start level 0.00～590.00（Hz） 0.01%
AH-87 PID sleep active time 0.0～100.0（s） 0.01%
AH-88 Setpoint boost before PID sleep enable 00（Disable）/01（Enable） 0.01%
AH-89 Setpoint boost time 0.00～100.00（s） 0.01%
AH-90 Setpoint boost value 0.00～100.00（s） 0.01%
AH-91 Minimum RUN time befor PID sleep 0.00～100.00（s） 0.01%
AH-92 Minimum active time of PID sleep 0.00～100.00（s） 0.01%
AH-93 PID sleep trigger selection 01 (Deviation value) /02 (Low feedback) /03 (Terminal [WAKE] input) 0.01%
AH-94 PID wake start level 0.00～100.00（%） 0.01%
AH-95 PID wake start time 0.00～100.00（s） 0.01%
AH-96 PID wake start deviation value 0.00～100.00（%） 0.01%
AJ-01 PID2 enable 00 (Disable) /01 (Enable) /02 (Enable (with reverse output)) 0.01%
AJ-02 PID2 deviation inverse 00（Disable）/01（Enable） 0.01%
AJ-03 PID2 unit selection refer to the separated list for unit 0.01%
AJ-04 PID2 scale adjustment(at 0%) −10000～10000 0.01%
AJ-05 PID2 scale adjustment(at 100%) −10000～10000 0.01%
AJ-06 PID2 scale adjustment(point position) 0～4 0.01%
AJ-07 Input source selection of Set-point for PID2
00 (Disable) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) 09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse
train input(internal)) /13 (Pulse train input(Option)) /15 (PID function)
0.01%
AJ-10 Set-point setting for PID2 0.00～100.00（%） Display range can be changed with ［AJ-04］, ［AJ-05］, ［AJ-06］ 0.01%
AJ-12
Input source selection of Process data for PID2
00 (Not use) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12
(Pulse train input(internal)) /13 (Pulse train input(Option))"
0.01%
AJ-13 PID2 proportional gain 0.0～100.0 0.01%
AJ-14 PID2 integral time constant 0.0～3600.0（s） 0.01%
AJ-15 PID2 derivative gain 0.00～100.00（s） 0.01%
AJ-16 PID2 output variable 0.00～100.00（%） 0.01%
AJ-17 PID2 Deviation over level 0.00～100.00（%） 0.01%
AJ-18 PID2 Feedback compare signal turn-off level 0.00～100.00（%） 0.01%
AJ-19 PID2 Feedback compare signal turn-on level 0.00～100.00（%） 0.01%
AJ-21 PID3 enable 00 (Disable) /01 (Enable) /02 (Enable (with reverse output)) 0.01%
AJ-22 PID3 deviation inverse 00（Disable）/01（Enable） 0.01%
AJ-23 PID3 unit selection refer to the separated list for unit 0.01%
AJ-24 PID3 scale adjustment(at 0%) −10000～10000 0.01%
AJ-25 PID3 scale adjustment(at 100%) −10000～10000 0.01%
AJ-26 PID3 scale adjustment(point position) 0～4 0.01%
AJ-27 Input source selection of Set-point for PID3
00 (Not use) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12
(Pulse train input(internal)) /13 (Pulse train input(Option))"
0.01%
AJ-30 Set-point setting for PID3 0.00～100.00（%） Display range can be changed with ［AJ-24］, ［AJ-25］, ［AJ-26] 0.01%
AJ-32 Input source selection of Process data for PID3
00 (Not use) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12
(Pulse train input(internal)) /13 (Pulse train input(Option))"
0.01%
AJ-33 PID3 proportional gain 0.0～100.0 0.01%
AJ-34 PID3 derivative gain 0.0～3600.0（s） 0.01%
AJ-35 PID3 derivative gain 0.00～100.00（s） 0.01%
AJ-36 PID3 output variable 0.00～100.00（%） 0.01%
AJ-37 PID3 Deviation over level 0.00～100.00（%） 0.01%
AJ-38 PID3 Feedback compare signal turn-off level 0.00～100.00（%） 0.01%
AJ-39 PID3 Feedback compare signal turn-on level 0.00～100.00（%） 0.01%
AJ-41 PID4 enable 00 (Disable) /01 (Enable) /02 (Enable (with reverse output)) 0.01%
AJ-42 PID4 deviation inverse 00（Disable）/01（Enable） 0.01%
AJ-43 PID4 unit selection refer to the separated list for unit 0.01%
AJ-44 PID4 scale adjustment(at 0%) −10000～10000 0.01%
AJ-45 PID4 scale adjustment(at 100%) −10000～10000 0.01%
AJ-46 PID4 scale adjustment(point position) 0～4 0.01%
AJ-47 Input source selection of Set-point for PID4
00 (Not use) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12
(Pulse train input(internal)) /13 (Pulse train input(Option))"
0.01%
AJ-50 Set-point setting for PID4 0.00～100.00（%） Display range can be changed with ［AJ-44］, ［AJ-45］, ［AJ-46］ 0.01%
AJ-52 Input source selection of Process data for PID4
00 (Not use) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12
(Pulse train input(internal)) /13 (Pulse train input(Option))"
0.01%
AJ-53 PID4 proportional gain 0.0～100.0 0.01%
AJ-54 PID4 derivative gain 0.0～3600.0（s） 0.01%
AJ-55 PID4 derivative gain 0.00～100.00（s） 0.01%
AJ-56 PID4 output variable 0.00～100.00（%） 0.01%
AJ-57 PID4 Deviation over level 0.00～100.00（%） 0.01%
AJ-58 PID4 Feedback compare signal turn-off level 0.00～100.00（%） 0.01%
AJ-59 PID4 Feedback compare signal turn-on level 0.00～100.00（%） 0.01%
