Omron CJ1W-EIP21 - 10-2010 User Manual

173
Setting Tag Data Links Section 6-2
Verifying the Network
Configuration
Compare the list of registered devices in the Network Configuration Window
with the devices connected on the EtherNet/IP network, and check the IP
addresses and device types. This function cannot be used to verify device
parameters.
1,2,3... 1. Connect the Network Configurator to the network.
2. The following progress monitor will be displayed to show the progress as
data is read from the network and compared.
3. The results of the comparison between the network configuration file and
data from the network are displayed as follows.
• Differences Not Found in the Comparison
• Differences Found in the Comparison
• Differences Found in the Device Type.
