29
Selecting the Network Devices Section 2-3
2-3 Selecting the Network Devices
2-3-1 Recommended Network Devices
The following table shows the devices recommended for use with the Ether-
Net/IP.
Note (1) Always use a switching hub when using tag data links in the network.
(2) If a repeater hub is used for EtherNet/IP tag data links (cyclic communi-
cations), the network’s communications load will increase, data collisions
will occur frequently, and stable communications will be impossible.
2-3-2 Network Devices Manufactured by OMRON
The following network devices are manufactured by OMRON for EtherNet/IP
networks.
2-3-3 Switching Hub Types
Unmanaged Layer 2 (L2)
Switching Hubs
These switching hubs use the Ethernet MAC address to switch ports. Ordi-
nary switching hubs have this function. Switching hub functions and settings
cannot be changed.
Managed Layer 2 (L2)
Switching Hubs
These switching hubs use the Ethernet address to switch ports. Switching hub
functions and settings can be changed using special software tools for switch-
ing hubs running on a network node. Analytical data can also be collected.
These switching hubs provide more-advanced functions than unmanaged
layer 2 switching hubs.
Part Maker Model number Inquires
Switching
Hub
Cisco Systems, Inc. Consult the manufacturer. Cisco Systems, Inc. Main Corpo-
rate HQ
Contec USA, Inc. Consult the manufacturer. CONTEC USA Inc.
Phoenix Contact Consult the manufacturer. Phoenix Contact USA Customer
Service
Hirschmann Automa-
tion and Control
Consult the manufacturer. Hirschmann Automation and Con-
trol (US)
Twisted-pair
cable
100BASE-TX
Fujikura F-LINK-E 0.5mm × 4P Fujikura America, Inc.
EtherNet/IP compliant cable ---
Connectors
(Modular
plug)
STP Plug
Panduit Corporation MPS588 Panduit Corporation US Headquar-
ters
Boots Tsuko Company MK boot (IV) LB Tsuko Company Japan Headquar-
ters
Name Model Function Number of
ports
Error detection
output
Switching Hub W4S1-03B Packet priority control (QoS):
EtherNet/IP control data priority
Failure detection: Broadcast
storm, LSI error detection, 10/
100Base-TX, Auto-Negotiation
3None
W4S1-05B 5 None
W4S1-05C 5 Provided.
