2-1
Programmable Multi-Axis Controller
The following provides the models and major specifications of the Programmable Multi-Axis Controller.
2-1-1
Model
Model Naming
CK3E-series Programmable Multi-Axis Controller model names are assigned according to the follow-
ing rule.
Maximum number of controlled axes
12: 8 axes
13: 16 axes
14: 32 axes
Number of EtherCAT ports
1:1 port
Always 0
CK3E
Model List
Model
Specifications
Memory Port Maximum number of controlled axes
CK3E-1210 Main memory: 1 GB
Flash memory: 1GB
EtherNet port: 1
EtherCA
T port: 1
8 axes
CK3E-1310 16 axes
CK3E-1410 32 axes
2-1-2
General Specifications
Item
Specifications
CK3E-1210 CK3E-1310 CK3E-1410
Enclosure Mounted in a panel
Grounding method Ground to less than 100 Ω.
Dimensions (height × depth ×
width)
130.4(H) × 28.6(D) × 170.9(W) mm
Weight 540 g max.
Unit power supply rated voltage 24 VDC (20.4 to 26.4 VDC)
Unit power current consumption 660 mA or less
2 Specifications
2-2
CK3E-series Programmable Multi-Axis Controller User’s Manual Hardware (I610)
