I/O Memory Allocation Section 9-3
204
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A203 to
A210
All Communi-
cations Port
Completion
Codes
These words contain the com-
pletion codes for the corre-
sponding port numbers when
network instructions (SEND,
RECV, CMND, or PMCR) have
been executed.
Words A203 to A210 correspond
to communications ports 0 to 7.
(The completion code for a given
port is cleared to 0000 when a
network instruction with that port
number is executed.)
Non-zero:
Error code
0000:
Normal
condition
Same as
CS/CJ-series
PLC.
A219 A21900
to
A21907
Communi-
cations Port
Error Flags
ON when an error occurred dur-
ing execution of a network in-
struction (SEND, RECV, CMND,
or PMCR). Bits 00 to 07 corre-
spond to communications ports 0
to 7.
(All of these flags are turned OFF
at the start of program execution
and the flag for a given port is
turned OFF when a network in-
struction with that port number is
executed.)
1: Error
occurred
0: Normal
condition
Same as
CS/CJ-series
PLC.
(Not cleared at
startup.)
A220 to
A259
A22000
to
25915
Basic I/O
Unit Input
Response
Times
These words contain the actual
input response times for CS/CJ-
series Basic I/O Units.
0 to 17
hexadeci-
mal
Not used.
A262
and
A263
All Maximum
Cycle Time
These words contain the maxi-
mum cycle time since the start of
PLC operation. The cycle time is
recorded in 8-digit hexadecimal
with the leftmost 4 digits in A263
and the rightmost 4 digits in
A262.
0 to
FFFFFFFF:
0 to
429,496,72
9.5ms
(0.1ms
units)
Same as
CS/CJ-series
PLC.
A264
and
A265
All Present
Cycle Time
These words contain the present
cycle time in 8-digit hexadecimal
with the leftmost 4 digits in A265
and the rightmost 4 digits in
A264.
0 to
FFFFFFFF:
0 to
429,496,72
9.5ms
Same as
CS/CJ-series
PLC.
A294 All Task Num-
ber when
Program
Stopped
This word contains the task
number of the task that was be-
ing executed when program exe-
cution was stopped because of a
program error.
(A298 and A299 contain the pro-
gram address where program
execution was stopped.)
Normal
tasks:
0000 to
001F (task
0 to 31)
Interrupt
tasks:
8000 to
80FF (task
0 to 255)
Same as
CS/CJ-series
PLC.
