Omron D4C - Page 18

F-26 Enclosed Switch D4C
Pre-wired Models
49 max.
40 max.
Rubber cap
XS2H-D421
49 max.
XS2H-D421
Rubber cap
40 max.
40 max.
67 max.
51.5 max.
XS2H-D421
12 dia. x 5 stainless steel roller
10 dia. stainless steel plunger
40 max.
54.2 max.
49 max.
XS2H-D421
Pin Plunger
Roller Plunger
Sealed Roller Plunger Sealed Pin Plunger
D4C-@001-@K1EJ@
D4C-@001-M1J@
D4C-@002-@K1EJ@
D4C-@002-M1J@
D4C-@031-@K1EJ@
D4C-@031-M1J@
D4C-@032-@K1EJ@
D4C-@032-M1J@
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia.
Depth: 6
Correct setting
position
10 dia. stainless
steel plunger
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia.
Depth: 6
12 dia. x 5 stainless
steel roller
0
Two, 5.1
+0.2
dia. holes
Spot facing 10.2 dia.
Depth: 6
