Omron D4C - Wiring Specifications

F-10 Enclosed Switch D4C
Pre-wired Models (Use VCTF Oil-resistant Cable)
1. Operation Indicator Lamp
1: Without operation indicator
2: 1 A at 125 VAC (with operation indicator)
3: 1 A at 30 VDC (with operation indicator)
2. Actuator
01: Pin plunger
02: Roller plunger
31: Sealed plunger
32: Sealed roller plunger
24: Roller lever (high-sensitivity model)
3. Wiring Specifications
DK1EJ: Pre-wired models
(3 conductors: DC specification, NC wiring)
AK1EJ: Pre-wired models
(3 conductors: AC specification, NC wiring)
M1J: Connector models for ASI devices
(2 conductors: NO wiring)
4. Cable length
03: 0.3 m
05: 0.5 m
10: 1 m
Wiring Specifications
Note: Since the above wiring specifications are different from those
for the D4CC, be careful not to mistake them.
Weather-resistant Models
1. Rated Current
1: 5 A at 250 VAC, 4 A at 30 VDC
2: 5 A at 125 VAC (with LED indicator)
3: 4 A at 30 VDC (with LED indicator)
4: 0.1 A at 125 VAC, 0.1 A at 30 VDC
5: 0.1 A at 125 VAC (with LED indicator)
6: 0.1 A at 30 VDC (with LED indicator)
2. Cable Specifications
2: VCTF oil-resistant cable (3 m)
3: VCTF oil-resistant cable (5 m)
3. Actuator
20: Roller lever
24: Roller lever (high-sensitivity model)
27: Variable roller lever
29: Variable rod lever
1 2 3 4
D4C-@0@@-@@@@@@
Internal switch Connector
COM 3
NC 2
NO 4
1 2 3
D4C-@@@-P
