5E2E
Specifications
Ratings/Characteristics
E2E
E2E-X@D@ DC 2-wire Models
Note: 1. Use the E2E within the range in which the setting indicator (green LED) is ON (except D2 models).
2. The response speed is an average value. Measurement conditions are as follows: standard sensing object, a distance of twice the standard sensing object,
and a set distance of half the sensing distance.
3. The residual voltage of each E2E model with the model number suffix “-M1J-T” is 5 V. When connecting an E2E model with the suffix “-M1J-T” to a device,
make sure that the device can withstand the residual voltage.
Size M8 M12 M18 M30
Type Shielded Unshielded Shielded Unshielded Shielded Unshielded Shielded Unshielded
Item E2E-X2D@ E2E-X4MD@ E2E-X3D@ E2E-X8MD@ E2E-X7D@ E2E-
X14MD@
E2E-X10D@ E2E-
X20MD@
Sensing distance 2 mm ±10% 4 mm ±10% 3 mm ±10% 8 mm ±10% 7 mm ±10% 14 mm ±10% 10 mm ±10% 20 mm ±10%
Set distance
(See note 1.)
0 to 1.6 mm 0 to 3.2 mm 0 to 2.4 mm 0 to 6.4 mm 0 to 5.6 mm 0 to 11.2 mm 0 to 8.0 mm 0 to 16.0 mm
Differential travel 15% max. of sensing distance 10% max. of sensing distance
Sensing object Ferrous metal (The sensing distance decreases with non-ferrous metal, refer to Engineering Data.)
Standard sensing object Iron, 8 x 8 x
1mm
Iron, 20 x 20 x
1mm
Iron,12 x 12 x
1mm
Iron,30 x 30 x
1mm
Iron, 18 x 18 x
1mm
Iron, 30 x 30 x
1mm
Iron,30 x 30 x
1mm
Iron, 54 x 54 x
1mm
Response speed (See
note 2.)
1.5 kHz 1.0 kHz 1.0 kHz 0.8 kHz 0.5 kHz 0.4 kHz 0.4 kHz 0.1 kHz
Power supply voltage
(operating voltage
range)
12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max.
Leakage current 0.8 mA max.
Control
output
Load cur-
rent
3 to 100 mA
Diagnostic output: 50 mA for -D1(5)S models
Residual
voltage
(See note
3.)
3 V max. (Load current: 100 mA, Cable length: 2 m. M1J-T models only: 5 V max.)
Indicator D1 Models: Operation indicator (red LED), setting indicator (green LED)
D2 Models: Operation indicator (red LED)
Operation mode
(with sensing object ap-
proaching)
D1 Models: NO
D2 Models: NC
For details, refer to Timing Charts.
Diagnostic output delay 0.3 to 1 s
Protection circuits Surge suppressor, output load short-circuit protection (for control and diagnostic output)
Ambient temperature Operating: –25° C to 70° C, Storage: –40° C to 85° C (with no icing or condensation)
Ambient humidity Operating/Storage: 35% to 95% (with no condensation)
Temperature influence ±15% max. of sensing dis-
tance at 23° C in the tempera-
ture range of –25° C to 70° C
±10% max. of sensing distance at 23° C in the temperature range of –25° C to 70° C
Voltage influence ±1% max. of sensing distance in the rated voltage range ±15%
Insulation resistance 50 MΩ min. (at 500 VDC) between current-carrying parts and case
Dielectric strength 1,000 VAC at 50/60 Hz for 1 min between current-carrying parts and case
Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance
500 m/s
2
10 times each in X,
Y, and Z directions
1,000 m/s
2
10 times each in X, Y, and Z directions
Degree of protection IEC 60529 IP67 (Pre-wired models, pre-wired connector models: JEM standard IP67g (waterproof and oil-proof))
Connection method Pre-wired models (standard length: 2 m), connector models, pre-wired connector models (standard length: 0.3 m)
Weight
(packed
state)
Pre-wired
models
Approx. 60 g Approx. 70 g Approx. 130 g Approx. 175 g
Pre-wired
connector
models
--- Approx. 40 g Approx. 70 g Approx. 110 g
Connector
models
Approx. 15 g Approx. 25 g Approx. 40 g Approx. 90 g
Material Case Stainless steel (SUS303) Brass-nickel plated
Sensing
surface
PBT (polybutylene terephthalate)
Cable PVC (polyvinyl chloride)
all E2E-@@@-U PUR/PE (polyurethane/polyethylene)
Clamping
nuts
Brass-nickel plated
Toothed
washer
Iron-zinc plated
Accessories Instruction manual
