Note: Standard cable length is 2 m. Models provided with a 5 m long cable are available. When ordering, specify the cable length by adapting the length of the cable
(e.g. E3F2-R4B4-E 5M). For other cable length please contact your OMRON sales representative.
Accessories (Order Separately)
For detailed information about Accessories, refer to the main chapter “Accessories” at the end of the document.
Sensor I/O Connectors
Diffuse-reflective
(background suppression)
0.1 m (fixed)
––2 m–
E3F2-LS10B4-M 2M E3F2-LS10C4-M 2M
–  ––
E3F2-LS10B4-M1-M E3F2-LS10C4-M1-M
*1.
Pre-wired connectors are available on request. Please contact your OMRON representative.
*2.
Order reflector separately. Models with reflector E39-R1S included are available. Please contact your OMRON representative.
*3.
with reflector E39-R1S
*4.
with reflector E39-R1
Name Sensing distance (typical)
*1
*1.
Values in parentheses indicate the minimum required distance between the sensor and reflector.
Remark Order code
Reflectors 3 m [100 mm] (axial types)
2 m [100 mm] (radial types)
60 x 40 mm E39-R1
4 m [100 mm] (axial types)
2 m [100 mm] (radial types)
60 x 40 mm E39-R1S
5 m [100 mm] (axial types)
2.5 m [100 mm] (radial types)
∅ 84 mm
E39-R7
6 m [100 mm] (axial types)
3 m [100 mm] (radial types)
100 x 100 mm E39-R8
5 m [100 mm] (axial types)
2.5 m [100 mm] (radial types)
80 x 80 mm E39-R40
Tape Reflectors 0.7 m [150 mm] (axial types)
1.1 m [150 mm] (axial types)
1.4 m [150 mm] (axial types)
35 x 10 mm E39-RS1
35 x 40 mm E39-RS2
80 x 70 mm E39-RS3
Lens Cap E39-F31
Mounting Bracket screw mount Y92E-B18
Cord Shape Cable type Order code
Standard Straight 2 m Four-wire type XS2F-D421-D80-A
5 m XS2F-D421-G80-A
L-shaped 2 m XS2F-D422-D80-A
5 m XS2F-D422-G80-A
Vibration-proof
robot cable
Straight 2 m XS2F-D421-D80-R
5 m XS2F-D421-G80-R
L-shaped 2 m XS2F-D422-D80-R
5 m XS2F-D422-G80-R
