A - 35
A Appendices
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
• This object sets the channel display of the Sensor with the unit number that is specified by the index.
• A value of 0000 hex is always read for this object.
• This object sets the eco mode of the Sensor with the unit number that is specified by the index.
• This object sets the key lock setting of the Sensor with the unit number that is specified by the index.
• This object sets the blinking setting of the Sensor with the unit number that is specified by the index.
• Set this object to 0001 hex to write data. It is always set to 0000 hex when reading data.
4014 + (N-1) × 80
hex
No_01 ... 30 Channel Display
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Channel Display
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Data Setting
0000 hex Channel display OFF
0001 hex Channel display ON
4015 + (N-1) × 80
hex
No_01 ... 30 Eco Function Setting
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Eco Function Setting
Range: 0000 to FFFF hex Unit: --- Default: 0000 hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Data Setting
0000 hex Eco function OFF
0001 hex Eco function ON
0002 hex Eco function LO
0003 to FFFF hex Not used.
4016 + (N-1) × 80
hex
No_01 ... 30 Key Lock Setting
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Key Lock Setting
Range: 0000 to FFFF hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Data Setting
0000 hex Key Lock OFF
0001 hex Key Lock ON
0002 to FFFF hex Not used.
4017 + (N-1) × 80
hex
No_01 ... 30 Display Blinking
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Display Blinking
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
