Omron E3V3 - Engineering Data

E3V3 E3V3
Retroreflector Specifications
Item E39-R3 E39-RSA E39-RSB
Detection distance (with E3V3) 5 to 100 cm 20 to 50 cm 20 to 80 cm
Directional angle 30° min.
Ambient
Operating --25°Cto55°C(--13°F to 131°F)
b
e
temperature
Storage --40°Cto70°C(--40°F to 158°F)
Ambient humidity
Operating 35% to 85%
b
e
u
d
y
Storage 35% to 95%
Enclosure rating IEC IP67 (see note 2)
Note: 1. The E39-R3, E39-RSA, and E39-RSB are polarizing reflectors.
2. Do not cut or scratch E39-R3, E39-RSA, or E39-RSB Reflectors, otherwise they will not be water resistant.
Engineering Data

PARALLEL OPERATING
RANGE (TYPICAL)
E3V3-T

1

REFLECTOR PARALLEL
MOVEMENT (TYPICAL)
E3V3-R

1

OPERATING RANGE
(TYPICAL)
E3V3-D

2
Parallel operating range Y (cm)
Detection distance X (m)
Parallel operating range Y (mm)
Detection distance X (m)
Operating position Y (mm)
Detection distance X (cm)
Reflector
placed
vertically

DETECTION DISTANCE VS.
OBJECT SIZE (TYPICAL)

COLOR OF OBJECT VS.
OPERATING RANGE
(TYPICAL)

DETECTION DISTANCE VS.
OBJECT SIZE (TYPICAL)
Detection distance (cm)
Size of object d (cm)
Parallel operating range Y (mm)
Detection distance X (mm)
Black carbon
White
paper
SUS (lustrous)
Black
carbon
White paper
Detection distance
X (mm)
SUS (lustrous)
Detectable object
(200 x 200 mm)
Detectable object: White paper
Detection distance (mm)
Size of object d (mm)
E3V3-D

2 E3V3-D

1E3V3-D

1
