E3V3 E3V3
Output
Configuration
Output CircuitsConnection
Method
Mode
Switch
PNP
(E3V3-
8
)
Light-ON Connect the pink
cord to the brown
cord. (see note)
Connector Pin
Arrangement
Operation
indicator
(Orange)
Stability
indicator
(Green)
Main
circuit
Brown
Black
Blue
Pink
Load
(relay)
0V
12 to 24 VDC
Operating selection
100 mA
max.
Dark-ON Connect the pink
cord to the blue
cord or
disconnect the
pink cord from the
blue cord (see
note)
Connector Pin
Arrangement
Operation
indicator
(Orange)
Stability
indicator
(Green)
Main
circuit
Brown
Black
Blue
Pink
Load
(relay)
0V
12 to 24 VDC
Operating selection
100 mA
max.
Note: The E3V3 Model with a junction connector has a white cord instead of a pink cord.
Emitter (NPN/PNP)
Connector Pin Arrangement
Main
circuit
12 to
24 VDC
Emitter
indicator
(orange)
Blue
Brown
TIMING CHARTS
Output
Configuration
Mode
Switch
Connection Method Timing Chart
NPN
(E3V3-
6
)
Light-ON Connect the pink
cord to the brown
cord. (see note)
Light indicator
(Orange)
ON
OFF
Output
transistor
Load
(relay)
Operate
Release
ON
OFF
(Between brown and black)
Light received
Light not received
Dark-ON Connect the pink
cord to the blue cord
or disconnect the
pink cord from the
blue cord. (see
note)
Light indicator
(Orange)
ON
OFF
Output
transistor
Load
(relay)
Operate
Release
ON
OFF
Light received
Light not received
(Between brown and black)
PNP
(E3V3-
8
)
Light-ON Connect the pink
cord to the brown
cord. (see note)
Light indicator
(Orange)
ON
OFF
Output
transistor
Load
(relay)
Operate
Release
ON
OFF
(Between blue and black)
Light received
Light not received
Dark-ON Connect the pink
cord to the blue cord
or disconnect the
pink cord from the
blue cord. (see
note)
Light indicator
(Orange)
ON
OFF
Output
transistor
Load
(relay)
Operate
Release
ON
OFF
Light received
Light not received
(Between blue and black)
Note: The E3V3 Model with a junction connector has a white cord instead of a pink cord.
