Omron E3X-DA-N - Teaching Functions

A-425E3X-DA-N
E3X-DA-N
Digital Fiber Amplifier
* Differential output digital fiber amplifier (E3X-DA11D/E3X-DA6D)
Applicable fiber unit characteristic
(Through-beam model)
Note: Refer to E3X-DA-N for the note of the fiber unit.
Sensing distance (mm) (Values in parentheses: When using the E39-F1 lens unit)
Standard object (mm) *1
Minimum sensing object
*2 (Opaque object) de-
fault
*1. The sensing object is operating.
*2. Value applied when the response time is set to 3-11. The value can be detected if the temperature varies within the operating ambient temperature. (Value when
the sensing object is operating)
Sensitivity
switching
HIGH LOW
11 steps can be
set
1 2 3-11 1 2 3-11
Fiber type
Re-
sponse
time
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
E32-ET11R 240 (1680) 280 (1960) 370 (2590) 140(980) 180(1260) 240 (1680)
1 mm dia. (0.01
mm dia.)
E32-ET21R 50 60 80 30 40 50
E32-T16WR 580 690 910 350 450 580 (0.3 mm dia.)*3
*3. The digital value is 1000 and the value can be detected in each detection area.
Refer to the E3X-DA-N for the note of the fiber unit.
(Reflective model)
E32-T16PR 380 450 600 230 290 380 (0.2 mm dia.)
Sensing distance (mm)*1
*1. Sensing distance indicates values for white paper.
Standard object (mm) *2
Minimum sensing object
*3 (Opaque object) de-
fault
*2. The sensing object is operating.
*3. Value applied when the response time is set to 3-11. The value can be detected if the temperature varies within the operating ambient temperature. (Value when
the sensing object is operating)
Sensitivity
switching
HIGH LOW
11 steps can be
set
1 2 3-11 1 2 3-11
Fiber type
Re-
sponse
time
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
E32-ED11R 80 90 120 45 60 80
150 x 150 (0.01
mm dia.)
E32-ED21R 13 15 20 7 10 13
25 x 25 (0.01 mm
dia.)
