A-424 Advanced Photoelectric Sensors
Connector type
Specifications that differ from those of the prewired type
* For waterproof type only, voltage resistance is 500 VAC 50/60 Hz 1 min
Insulation resistance
20 M min. at 500 VDC
Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute
Vibration resistance 10 to 55 Hz, 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions
Degree of protection IEC 60529 IP50 (with Protective Cover attached)
lEC 60529
IP66 (with
protective
cover at-
tached)
IEC 60529
IP50 (with
protective
cover
attached)
Connection method Prewired models (standard length: 2 m)
Weight (Packed state) Approx. 100 g Approx. 110 g Approx. 100 g
Mate-
rial
Case PBT (polybutylene terephthalate)
Cover Polycarbonate
Polyethersul-
fone
Accessories Instruction manual
Type
Standard
models
Monitor-out-
put models
Mark-detecting models
Infrared
models
Water-resis-
tant models
(See note.)
Twin-out-
put models
Model
NPN
output
E3X-DA6 E3X-DA7 E3X-DAB6 E3X-DAG6 E3X-DAH6 E3X-DA14V E3X-DA6TW
Item
PNP
output
E3X-DA8 E3X-DA9 E3X-DAB8 E3X-DAG8 E3X-DAH8 E3X-DA44V E3X-DA8TW
Connection method Connector type M8 connector Connector
Weight (Packed state) Approx. 55 g 65 g Approx. 55 g
Type
Standard
models
Monitor-out-
put models
Mark-detecting models
Infrared
models
Water-resis-
tant models
Twin-output
models
Model
NPN
output
E3X-DA11-N E3X-DA21-N E3X-DAB11-N E3X-DAG11-N E3X-DAH11-N E3X-DA11V E3X-DA11TW
Item
PNP
output
E3X-DA41-N E3X-DA51-N E3X-DAB41-N E3X-DAG41-N E3X-DAH41-N E3X-DA41V E3X-DA41TW
Amplifier unit Connectors
Item Model E3X-CN11/21/22 E3X-CN12
Rated current 2.5 A
Rated voltage 50 V
Contact resistance
20 m max. (20 mVDC max., 100 mA max.) [By connection with
amplifier unit and connection with adjacent connector
(except conductor resistance of cable)]
No. of insertions
50 times (By connection with amplifier unit and connection with ad-
jacent connector)
Material
Housing PBT (polybutylene terephthalate)
Contacts Phosphor bronze/gold-plated nickel
Weight
(Packed state)
Approx. 55 g Approx. 25 g
Mobile Console
Item Model E3X-MC11
Supply volt-
age
Charged with AC adapter
Connection
method
Connected via adapter
Weight
(packed state)
Approx. 580 g (Console
only: 120 g)
For details of the Mobile Console, refer
to the instruction manual attached to the
product.
