Omron E5*C-B Series User Manual

6 Parameters
6 - 26
E5@C Digital Temperature Controllers User’s Manual (H174)
These parameters set the set points when the multi-SP function is used.
sp-0
SP 0
The Number of Multi-SP Points parameter must be
set to 2 to 8 and the Event Input 1 Assignment to
Event Input 6 Assignment parameters must not be
set to “Multi-SP No. switching bit 0” to “Multi-SP
No. switching bit 2.”
sp-1
SP 1
sp-2
SP 2
sp-3
SP 3
sp-4
SP 4
sp-5
SP 5
sp-6
SP 6
sp-7
SP 7
The values set in these parameters can be selected by operating the keys on the front panel
or by using event inputs.
• When the set point has been changed, the set value of the set point (0 to 7) selected by
the multi-SP inputs is also changed to the same value.
• The decimal point position depends on the selected sensor. During analog input, it
depends on the Decimal Point parameter setting.
 Related Parameters
Process Value/Set Point (Operation Level): Page 6-8
Input Type (Initial Setting Level): Page 6-43
Event Input Assignment (Initial Setting Level): Page 6-57
Number of Multi-SP Points (Advanced Function Setting Level): Page 6-63
Function
Setting
Setting range Unit Default
SP lower limit to SP upper limit EU 0
See
See
