Omron E5*C-B Series User Manual

A Appendices
A - 10
E5@C Digital Temperature Controllers User’s Manual (H174)
A-2 Current Transformer (CT)
*1 The maximum continuous current of the E5@C is 50 A.
• E54-CT1
A-2-1 Specifications
Item Specifications
Model number E54-CT1 E54-CT3 E54-CT1L E54-CT3L
Max. continuous current
50 A AC
120 A AC
*1
50 A AC
120 A AC
*1
Dielectric strength 1,000 VAC (for 1 min) 1,500 VAC (1 min)
Vibration resistance
50 Hz, 98 m/s
2
Weight Approx. 11.5 g Approx. 50 g Approx. 14 g Approx. 57 g
Accessories None Armature (2), Plug (2) None None
A-2-2 Dimensions (Unit: mm)
30
21
15
5.8 dia.
25
2.5
40
10.5
2.8
7.5
5
Two, 3.5 dia.
10
Filler
(epoxy)
Case
