6 Parameters
6 - 44
E5@C Digital Temperature Controllers User’s Manual (H174)
in-h
Scaling Upper Limit
The input type must be set for an analog input.
in-l
Scaling Lower limit
dp
Decimal Point
• The Decimal Point parameter specifies the decimal point position of parameters (set
point, etc.) whose unit is EU.
• Scaling Upper Limit, Scaling Lower Limit
• Decimal Point
 Related Parameters
Input Type (Initial Setting Level): Page 6-43
d-u
Temperature Unit The input type must be set for a temperature input.
• Set the temperature input unit to either °C or °F.
 Related Parameters
Input Type (Initial Setting Level): Page 6-43
Function
Setting
Parameter name Setting range Default
Scaling Upper Limit Scaling lower limit + 1 to 9999 100
Scaling Lower Limit −1999 to scaling upper limit − 10
Parameter name Setting range Default
Decimal Point 0 to 3 0
Set value Settings Example
0 0 digits past decimal point 1234
1 1 digits past decimal point 123.4
2 2 digits past decimal point 12.34
3 3 digits past decimal point 1.234
See
See
Function
Setting
* The temperature unit is not displayed by the E5DC and E5DC-B.
Setting range Default
c: °C, f: °F c
See
See
