Omron E5C-T Series User Manual

4 - 41
4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-7 Setting Programs
4
4-7-5 Creating the Program
z Setting Example
This parameter sets the segment format for the specified segment number.
z Related Parameters
z Setting Example
This parameter sets the SP for the specified segment number.
z Related Parameters
This procedure shows how to select segment 0.
Operating Procedure
1 Press the M Key several times in the Program Setting Level to
select the Display Segment Selection parameter.
Program Setting Level
2 Press the U or D Key to select 0.
The default is end.
* If anything other than end is selected and you press the M Key,
the first segment parameter for the specified segment number is
displayed.
Setting the Segment Format Parameter (for Rate of Rise
Programming)
Parameter name Setting range Default Level
Segment n Format ramp: Ramp
soak: Soak
step: Step
ramp
Program Setting Level
The following example shows how to set a ramp segment.
Operating Procedure
1 Specify a segment number for the Display Segment Selection
parameter and press the M Key several times to select the
Segment Format parameter.
Program Setting Level
2 Press the U or D Key to set ramp (ramp).
The default is ramp (ramp).
Setting the Segment SP Parameter
Parameter name Display Setting range Unit Default Level
Segment n SP
sp
SP lower limit to SP upper
limit
EU 0 Program Setting
Level
end
d.seg
Display Segment
Selection
0
d.seg
ramp
styp
Segment 0
Format
ramp
styp
