E5@C-T Digital Temperature Controllers User’s Manual (H185)
z Setting Example
This parameter sets the segment slope for the specified segment number.
z Related Parameters
z Setting Example
This parameter sets the segment time for the specified segment number.
z Related Parameters
*The unit is set in the Program Time Unit parameter (default: h-m (hours and minutes))
The following example shows how to set 50.
Operating Procedure
1 Specify a segment number for the Display Segment Selection
parameter and press the M Key several times to select the
Segment SP parameter.
Program Setting Level
2 Press the U or D Key to set 50 (50°C).
The default is 0.
Setting the Segment Slope Parameter (for Rate of Rise
Programming)
Parameter name Display Setting range Unit Default Level
Segment n Slope
pr 0 to 9999
EU/Time Unit
of Ramp Rate
0 Program Setting
Level
The following example shows how to set 2.
Operating Procedure
1 Press the M Key several times from the Display Segment
Selection parameter to select the Segment 1 Slope parameter.
Program Setting Level
2 Press the U or D Key to select 2.
The default is 0.
Setting the Segment Time
Parameter name Display Setting range Unit Default Level
Segment n Time
time 0.00 to 99.59
Hours and minutes, or
minutes and seconds*
0.00 Program Setting
Level
0
sp
Segment 0
set point
50
sp
0
pr
Segment 1
Slope
2
pr
