3 Communications Data for CompoWay/F
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
3-1 Variable Area (Setting Range) List
3
C5 (85) 0060 PID 7 Proportional
Band
H'00000001 to H'0000270F (0.1 to 999.9) PID Setting
to to
C5 (85) 006C PID 7 Manual Reset
Value
H'00000000 to H'0000270F (0 to 9999)
C5 (85) 0070 PID 8 Proportional
Band
H'00000001 to H'0000270F (0.1 to 999.9)
to to
C5 (85) 007C PID 8 Manual Reset
Value
H'00000000 to H'0000270F (0 to 9999)
C9 (89) 0000 Upload Setting 1 H'00000000 to H'000000B3 (0 to 179) Communications
setting
C9 (89) 0001 Upload Setting 2 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0002 Upload Setting 3 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0003 Upload Setting 4 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0004 Upload Setting 5 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0005 Upload Setting 6 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0006 Upload Setting 7 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0007 Upload Setting 8 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0008 Upload Setting 9 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0009 Upload Setting 10 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000A Upload Setting 11 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000B Upload Setting 12 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000C Upload Setting 13 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000D Upload Setting 14 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000E Upload Setting 15 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 000F Upload Setting 16 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0010 Upload Setting 17 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0011 Upload Setting 18 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0012 Upload Setting 19 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0013 Upload Setting 20 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0014 Upload Setting 21 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0015 Upload Setting 22 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0016 Upload Setting 23 H'00000000 to H'000000B3 (0 to 179)
C9 (89) 0017 Download Setting 1 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0018 Download Setting 2 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0019 Download Setting 3 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001A Download Setting 4 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001B Download Setting 5 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001C Download Setting 6 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001D Download Setting 7 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001E Download Setting 8 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 001F Download Setting 9 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0020 Download Setting 10 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0021 Download Setting 11 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0022 Download Setting 12 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0023 Download Setting 13 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0024 Download Setting 14 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0025 Download Setting 15 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0026 Download Setting 16 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0027 Download Setting 17 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0028 Download Setting 18 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 0029 Download Setting 19 H'0000001E to H'000000B3 (30 to 179)
C9 (89) 002A Download Setting 20 H'0000001E to H'000000B3 (30 to 179)
Variable
type
Address Parameter name Setting (monitor) value Level
