7 Component Communications
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
7-1 Component Communications
7
7-1-2 Wiring
Wire the E5@C-T Controllers as shown below.
E5CC-T/EC-T/AC-T
7-1-2 Wiring
13
14
No.0 No.1 No.2
B(+)
A(
−)
13
14
B(+)
A(
−)
13
14
B(+)
A(
−)
No.n
13
14
B(+)
A(
−)
120 Ω (1/2 W)
terminating resistance
120 Ω (1/2 W)
terminating resistance
