Omron E5CC-T Communications Manual

3 - 27
3 Communications Data for CompoWay/F
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
3-1 Variable Area (Setting Range) List
3
Variable
type
Address Parameter name Setting (monitor) value Level
DA (9A) 0000 Program 0 No. of
Segments Used
H'00000001 to H'00000020 (1 to 32) Program
setting
DA (9A) 0001 Program 0 PID Set
No.
H'00000000 to H'00000008 (0 to 8), (0): Automatic
selection
DA (9A) 0002 Program 0 Alarm
Value 1
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0003 Program 0 Alarm
Upper Limit 1
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0004 Program 0 Alarm
Lower Limit 1
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0005 Program 0 Alarm
Value 2
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0006 Program 0 Alarm
Upper Limit 2
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0007 Program 0 Alarm
Lower Limit 2
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0008 Program 0 Alarm
Value 3
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 0009 Program 0 Alarm
Upper Limit 3
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 000A Program 0 Alarm
Lower Limit 3
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 000B Program 0 Alarm
Value 4
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 000C Program 0 Alarm
Upper Limit 4
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 000D Program 0 Alarm
Lower Limit 4
H'FFFFF831 to H'0000270F (−1999 to 9999)
DA (9A) 000E Program 0
Program
Repetitions
H'00000000 to H'0000270F (0 to 9999)
DA (9A) 000F Program 0
Program Link
Destination No.
H'FFFFFFFF (−1): No link
H'00000000 to H'00000007 (0 to 7)
DA (9A) 0010 Program 0 Time
Signal 1 Set
Segment
H'00000000 (0) to No. of segments used − 1
DA (9A) 0011 Program 0 Time
Signal 1 ON Time
H'00000000 to H'00009959 (0.00 to 99.59) (hours,
minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes,
seconds)
DA (9A) 0012 Program 0 Time
Signal 1 OFF Time
H'00000000 to H'00009959 (0.00 to 99.59) (hours,
minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes,
seconds)
DA (9A) 0013 Program 0 Time
Signal 2 Set
Segment
Hí00000000 (0) to No. of segments used − 1
DA (9A) 0014 Program 0 Time
Signal 2 ON Time
H'00000000 to H'00009959 (0.00 to 99.59) (hours,
minutes)
H'00000000 to H'00009959 (0.00 to 99.59) (minutes,
seconds)
