E5@C Digital Temperature Controllers User’s Manual (H174)
E5CC-B (Models with Push-In Plus Terminal Blocks)
*1 Options with 001 and 002 cannot be selected if a linear current output is selected for the control output.
The control output cannot be used as a simple transfer output.
(1) (2) (3) (4) (5) (6) (7) Meaning
C48 × 48 mm
Control output 1 Control output 2
R X Relay output None
Q X Voltage output (for driving SSR) None
*1 C X Linear current output None
2 2 (one common)
A 100 to 240 VAC
D 24 VAC/DC
B Push-In Plus terminal blocks
M Universal input
Event
inputs
Communi
cations
Remote
SP input
HB alarm and HS
alarm
Transfer
output
000 --- --- --- --- ---
001 2 --- --- 1 ---
002 --- RS-485 --- 1 ---
004 2 RS-485 --- --- ---
006 2 --- --- --- Provided.
--
-
E5CC B
-
-
(1)
(2) (3) (4) (5) (6) (7)
