2 - 5
2 Preparations
E5@C Digital Temperature Controllers User’s Manual (H174)
2-1 Installation
2
2-1-1 Dimensions (Unit: mm)
 E5DC-B
The figure below shows the Push-in Plus Terminal Unit attached to the Main Unit.
 E5GC
486
(90)
110
(6.5)
96
22.5 (6.5)22.5
+1.15 -0.2
90
+1.15 -0.2
4
35
90
Adapter (sold separately)
Main Unit Push-in Plus
Terminal Unit
24
48
63.6 4
1
1
90
22
40.8
44.8
22
24
48
63.6 4 93
22
40.8
44.8
22
Models with Screwless Clamp Terminal Blocks
Models with Screw Terminal Blocks
