2 Preparations
2 - 14
E5@C Digital Temperature Controllers User’s Manual (H174)
• Removing a Unit
Pull down on the DIN Track Hook with a flat-blade screwdriver and lift up the Unit.
Removing the Main Unit
End Plate Installation
Make sure to attach PFP-M End Plates to the ends of the Units.
Mounting the DIN Track
Refer to Mounting the DIN Track on page 2-13.
(1)
(1) Push in the hooks.
(2) Pull out the Main Unit.
Individual Mounting Group Mounting
(1)
(2)
To Next Page
