2 - 27
2 Preparations
E5@C Digital Temperature Controllers User’s Manual (H174)
2-2 Using the Terminals
2
2-2-1 E5CC Terminal Block Wiring Example
Model Numbers
The options specification of the E5CC is given in the following location in the model number.
* These cannot be selected if 5 (screw terminals with cover) is selected for the terminal type.
Options
Code Specification Remarks
000 None
001 Event inputs 1 and 2, and
CT1
002* Communications (RS-485)
and CT1
003 Communications (RS-485),
CT1, and CT2
004 Communications (RS-485),
and event inputs 3 and 4
005 Event inputs 1 to 4
006 Event inputs 1 and 2, and
transfer output
Transfer output:
Current: 4 to 20 mA DC
Voltage: 1 to 5 VDC
007 Event inputs 1 and 2, and
remote SP input
Remote SP input:
Current: 4 to 20 or 0 to 20 mA DC
Voltage: 1 to 5, 0 to 5, or 0 to 10 VDC
E5CC-@@ @ @ @ M-@@@
Options
