Omron E5CC User Manual

2 - 39
2 Preparations
E5@C Digital Temperature Controllers User’s Manual (H174)
2-2 Using the Terminals
2
2-2-4 E5EC/E5AC Terminal Block Wiring Example
 Model Numbers
The options specification of the E5EC/E5AC is given in the following location in the model number.
Transfer Output
Current: 4 to 20 mA DC
Voltage: 1 to 5 VDC
Remote SP Input
Current: 4 to 20 or 0 to 20 mA DC
Voltage: 1 to 5, 0 to 5, or 0 to 10 VDC
Options
Code Specification
000 None or potentiometer input (Position-proportional Models only)
004 Communications (RS-485), and event inputs 1 and 2
Potentiometer input (Position-proportional Models only)
005 Event inputs 1 to 4
008* Communications (RS-485), event inputs 1 and 2, and CT1
009 Communications (RS-485), event inputs 1 and 2, CT1, and CT2
010 Event inputs 1 to 4, and CT1
011 Event inputs 1 to 6, CT1, transfer output, and remote SP input
012* Communications (RS-485), event inputs 1, 2, 5, and 6, CT1, transfer output, and remote
SP input
013 Event inputs 1 to 6, transfer output, and remote SP input
014 Communications (RS-485), event inputs 1, 2, 5, and 6, transfer output, and remote SP
input
Potentiometer input (Position-proportional Models only)
E5EC-@@ @ @ S M-@@@
Options

Omron E5CC Specifications

General

Number of Display Digits	4 digits
Number of Control Outputs	1
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage, Analog current
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Display Type	LCD
Size	48 x 48 mm
Mounting Method	Panel mount
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25% to 85% RH
Protection Rating	IP66
