Basic type digital temperature controller E5GN 5
Models with Analog Inputs
Models with One Control Output and a 100 to 240-VAC Power Supply
Note: Models with analog inputs do not display the temperature unit.
Models with One Control Output and a 24-VAC/VDC Power Supply
Accessories (Order Separately)
USB-Serial Conversion Cable
Waterproof Packing
Current Transformers (CTs)
CX-Thermo Support Software
Note: The E5GN is supported by CX-Thermo version 4.2 and higher.
Case color
Control
output
Control
mode
*1
*1.
If heating/cooling control mode is used, an auxiliary output is used as a control output for the cooling side. The number of auxiliary outputs that can be used will
decrease by one. Also, the signal for the control output for the cooling side will be a relay output.
No. of
auxiliary
outputs
Detection of
heater
burnout,
SSR failure,
and heater
overcurrent
No. of event
inputs
Transfer
output
*2
*2.
A current control output can be used as the transfer output. In that case, an auxiliary output is used as the control output. (This is not possible for models without
an auxiliary output.) The control output will be a relay output. The number of auxiliary outputs that can be used will decrease by one.
Communi
cations
Previous model
New model
Thermocou-
ple input
Resistance
thermome-
ter input
Black
Current
output
Standard or
heating/
cooling
1 --- ---
Transfer
output using
control
output
--- --- --- E5GN-C1L-C
Case color
Control
output
Control
mode
*1
*1.
If heating/cooling control mode is used, an auxiliary output is used as a control output for the cooling side. The number of auxiliary outputs that can be used will
decrease by one. Also, the signal for the control output for the cooling side will be a relay output.
No. of
auxiliary
outputs
Detection of
heater
burnout,
SSR failure,
and heater
overcurrent
No. of event
inputs
Transfer
output
*2
*2.
A current control output can be used as the transfer output. In that case, an auxiliary output is used as the control output. (This is not possible for models without
an auxiliary output.) The control output will be a relay output. The number of auxiliary outputs that can be used will decrease by one.
Communi
cations
Previous model
New model
Thermocou-
ple input
Resistance
thermome-
ter input
Black
Current
output
Standard or
heating/
cooling
1 --- ---
Transfer
output using
control
output
--- --- ---
E5GN-C1LD-
C
Model
E58-CIFQ1
Model
Y92S-32
Hole diameter Model
5.8 dia. E54-CT1
12.0 dia. E54-CT3
Model
EST2-2C-MV4
H07E-EN-01+E5GN+Datasheet.fm Seite 5 Mittwoch, 18. November 2009 4:41 16
