E8F2 E8F2
4
Item E8F2-
A01C
E8F2-
B10C
E8F2-
AN0C
E8F2-
D01C
E8F2-
D10C
E8F2-
DN0C
E8F2-
A01B
E8F2-
B10B
E8F2-
AN0B
Temperature influence ±3% FS max.
Ambient temperature
Operating:
0°Cto55°C(32°F to 131°F)
Storage:
-- 1 0 °Cto60°C(14°F to 140°F)
with no icing
Ambient humidity Operati ng/Storage: 35% to 85% (with no condensation)
Voltage influence ±1.5% FS max.
Insulation resistance 100 MΩ min. (at 500 VDC ) between current-carry parts and case
Dielectric strength 1,000 VAC at 1 min
Vi bration resistance Destruction: 10 to 500 Hz, 1.0-mm doubl e amplitude or 150 m/s
2
,3timeseachfor11mininX,
Y,and Z directions
Shock resistance 300 m/s
2
(30G) 3 times each in X, Y, and Z di rections
Degree of protection IEC 60529, IP50
Pressure port 1/8 NPT male screw and M5 female screw
Connection method Pre-wi red (standard length: 2 m)
Cable Approved by UL
Weight (incl. packing material) Approx. 110 g (3.88 oz)
Material Pressure port: aluminum die cast
Case: heat-resistant AB S
Accessories Mounting bracket
Instruction sheet
Note: 1. The current consumption is approximately 43 mA in energy-saving mode.
2. Display Example of D igi tal Indicator
Model Setti ng uni t
kPa psi
Applied
pressure
Digital display
Applied
pressure
Digital display
E8F2-A01C/E8F2-A01B 100 1 0 0 0
E8F2-B10C/E8F2-B10B 1,000 1 0 0 0
E8F2-AN0C/E8F2-AN0B --101 -- 1 0 1 0
E8F2-D01C 14.5 1 4 5 0
E8F2-D10C 145 1 4 5 0
E8F2-DN0C -14.5 -1 4 6 0
Note: The “
.
” in the display indicates the decimal point. Its position will not change unless the setting unit is changed.
