Models with Direct UNI-WIRE Connection Enable Simplification of the Picking System Wiring
Up to 64 Picking Sensors can be connected to a single UNI-WIRE Interface Unit.
Ordering Information
Sensors
*1. The UNI-WIRE SYSTEM is a wire-saving system developed jointly by NKE Corporation and Kuroda Precision Industries, Ltd.
*2. Models with PNP outputs are also available. To order PNP Models, replace A with C in the model number for a Pre-wired Model and B with D in the model number
for a Pre-wired Connector Model (Example: F3W-D052C).
*3. The XS2F-D521-@G0 is the applicable connector cable. The colors of the external sheathes of the conductors, however, are different. Refer to the XS2.
Accessories (Order Separately)
Mounting Brackets Protective Bracket
Sensing
method
Appearance
Connection
method
(cable length)
Sensing
distance
Beams Sensing
width
(mm)
Output type
External
indicator
Model
Gap Qty
Through-
beam
Pre-wired (5 m)
25 mm 5 100
NPN open
collector
--- F3W-D052A *2
Possible F3W-D052AP*2
Pre-wired
connector (2 m)
--- F3W-D052B *2, 3
Possible F3W-D052BP*2, 3
Pre-wired (2 m)
UNI-WIRE
SYSTEM
direct
connection *1
--- F3W-D052U
Possible F3W-D052UP
Control panel
SYSMAC CS1,
α Series
Interface Unit
(manufactured by NKE)
Trunk line (e.g., cabtyre cable
with 4 conductors)
T-branch pressure-
welding connector
Detachable T-branch
pressure-welding connector
(manufactured by NKE)
Trunk line (flat cable
with 4 conductors)
Branch line (flat cable
with 4 conductors)
Parts box
Picking Sensors with Direct UNI-WIRE Connection
Output Unit with 1 or 2 points
(manufactured by NKE)
Rotary indicator/buzzer
Infrared LED
3 m
Appearance Model Qty Remarks
F39-L10 2
L-shaped Mounting
Bracket
(mounting screws
included)
F39-L11 2
Flat Mounting
Bracket
(mounting screws
included)
Appearance Model Qty
F39-L12
One each for Emitter and
Receiver
(mounting screws
included)
http://www.ia.omron.com/
2
(c)Copyright OMRON Corporation 2008 All Rights Reserved.
