5.1. Setting Communications for Vision Sensor
Please follow the procedures below to set the communications for the Vision Sensor.
1
Select [Tool] - [Configuration
copy] in the menu bar.
2
Select “Select a sensor
controller project” in the [Load]
tab.
Select the FHdata folder in the
folder outputted by using the
data set output tool for the
robot vision.
3
Click [Execute] to restart it.

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
