6-axis robot
4-axis robot
Communication
settings (Comm.
setting)
The timeout for communications between the Vision Sensor and
the robot controller can be set.
WARNING
Clicking [Jog operation] or [Robot move] drives the robot.
Operate the robot in the state whereby pressing the [Emergency stop]
button can stop its motion anytime.
CAUTION
When the robot moves to Z-axis direction, check its motion by visual
observation and not by camera image.
