Solid State Relays G3@-VD G3F/G3FD 215
Ordering Information
■ List of Models
Note: 1. Product is labelled “250 VAC”.
2. Product is labelled “50 VDC”.
3. When ordering, specify the rated input voltage.
■ Accessories (Order Separately)
Connecting Sockets
Refer to page 297 for details.
Specifications
■ Ratings (at an Ambient Temperature of 25°C)
Input
Isolation Zero cross
function
Indicator Rated output load Rated input voltage Model
Photocoupler Yes Yes 3 A at 100 to 240 VAC (See note 1.) 5 to 24 VDC G3F-203SN-VD
2 A at 100 to 240 VAC (See note 1.) 100/110 VAC G3F-202SN-VD
200/220 VAC
Phototriac coupler No 3 A at 100 to 240 VAC (See note 1.) 5 VDC G3F-203SLN-VD
12 VDC
24 VDC
Photocoupler 3 A at 4 to 48 VDC (See note 2.) 5 to 24 VDC G3FD-X03SN-VD
2 A at 5 to 110 VDC 100/110 VAC G3FD-102SN-VD
200/220 VAC
5 to 24 VDC
Photocoupler Yes No 3 A at 100 to 240 VAC (See note 1.) 4 to 24 VDC G3F-203S-VD
Phototriac coupler No 5 VDC G3F-203SL-VD
12 VDC
24 VDC
Photocoupler 3 A at 4 to 48 VDC (See note 2.) 4 to 24 VDC G3FD-X03S-VD
2 A at 5 to 110 VDC G3FD-102S-VD
Item PYF08A-E PY08 PY08-02 PY08QN(2)
Connecting Front connecting Back connecting
Mounting method/
Terminal type
Track mounted/
screw terminals
Solder terminals PCB terminals Wrapping terminals
Hold-down clip PYC-A1 PYC-P
Model Rated voltage Operating voltage Impedance Voltage level
Must operate voltage Must release voltage
G3F-203SN-VD 5 to 24 VDC 4 to 28 VDC 15 mA max. (See note.) 4 VDC max. 1 VDC min.
G3F-202SN-VD 100/110 VAC 75 to 125 VAC 41 k
Ω±20% 75 VAC max. 20 VAC min.
200/220 VAC 150 to 250 VAC 72 k
Ω±20% 150 VAC max. 40 VAC min.
