Omron G3F - Characteristics

Solid State Relays G3@-VD G3F/G3FD 217
■ Characteristics
Item G3F-203SN-VD
G3F-202SN-VD
G3F-203S-VD
G3F-203SLN-VD
G3F-203SL-VD
G3FD-X03SN-VD
G3FD-X03S-VD
G3FD-102SN-VD G3FD-102S-VD
Operate time 1/2 of load power
source cycle + 1 ms
max. (DC input)
3/2 of load power
source cycle + 1 ms
max. (AC input)
1 ms max. 0.5 ms max. 0.5 ms max. (DC in-
put)
20 ms max. (AC input)
0.5 ms max.
Release time 1/2 of load power
source cycle + 1 ms
max. (DC input)
3/2 of load power
source cycle + 1 ms
max. (AC input)
1/2 of load power
source cycle + 1 ms
max.
2 ms max. 2.5 ms max. (DC in-
put)
20 ms max. (AC input)
2.5 ms max.
Output ON voltage drop 1.6 V (RMS) max. 1.5 V max.
Leakage current 5 mA max. (at
100 VAC)
10 mA max. (at
200 VAC)
2.5 mA max. (at
100 VAC)
5 mA max. (at
200 VAC)
5 mA max. (at
50 VDC)
0.1 mA max. (at
100 VDC)
0.1 mA max. (at
100 VDC)
Insulation resistance 100 M
Ω min. (at 500 VDC)
Dielectric strength 2,000 VAC, 50/60 Hz for 1 min 1,500 VAC, 50/60 Hz for 1 min
Vibration resistance Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude
Shock resistance
Destruction: 1,000 m/s
2
Ambient temperature Operating: –30°C to 80°C (with no icing or condensation)
Storage: –30
°C to 100°C (with no icing or condensation)
Ambient humidity Operating: 45% to 85%
Certified standards G3F: UL508, CSA C22.2 No. 14, EN60947-4-3
G3FD: UL508, CSA C22.2 No. 14, EN60950
Weight Approx. 50 g
