Omron G3F - Engineering Data; Dimensions

218 Solid State Relays G3@-VD G3F/G3FD
Engineering Data
Load Current vs. Ambient Temperature Characteristics
One Cycle Surge Current: Non-repetitive
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Ambient temperature (°C)
Ambient temperature (°C)
Load current (A) Load current (A)
G3F-203SN-VD/203S-VD/203SLN-VD/
203SL-VD
G3FD-X03SN-VD/X03S-VD
G3F-202SN-VD
G3FD-102SN-VD/102S-VD
2010
Non-repetitive (Keep the inrush current to half the rated value if it occurs repetitively.)
G3FD-X03SN-VD/X03S-VD G3FD-102SN-VD/102S-VD
Inrush current (A. Peak)
Ener
g
ized time (ms)
Inrush current (A. Peak)
Ener
g
ized time (ms)
Inrush current (A. Peak)
Ener
g
ized time (ms)
G3F-203SN-VD/203S-VD/202SN-VD/
203SLN-VD/203SL-VD
1
5
9
13
4
8(+)
12(−)
14
−
+
−
+
(+)
(−)
( )
Load
Input
Load
Input voltage
28 max.
21.5 max.
36.5 max.
42.5 max.
Terminal Arrangement/
Internal Connections
Load power
supply
Note: The plus and minus symbols shown
in parentheses are for DC loads.
